Whelen 295SLSA6 Siren & Light Controller

The Whelen 295 Siren & Light Controller is a versatile and high-performance control solution for emergency vehicles, meeting SAE J1849 and California Title XIII requirements when paired with a 100-watt Whelen speaker. It combines hands-free operation, 18 customizable Scan-Lock™ siren tones, and dual 100-watt speaker support to deliver effective, reliable warnings in critical situations. Featuring a programmable slide switch, six customizable switches, and PA volume control with push-to-talk (PTT) override, it enables precise, adaptable control. Additional safety features include SI TEST® for system diagnostics, "Siren in Use" and "Siren Disable" indicators, and over/under voltage protection, with added input polarity and short-circuit safeguards. The controller offers LED backlit buttons for night visibility, a quick-copy function to replicate settings without a computer, and a bail-strap mount for easy installation.

Tech Specs:

• Input Voltage: 12.8 VDC ±20%
• Input Current: @15 VDC @ 5.5 OHMS16 AMPS MAX
• Input Fuse: 20 AMPS
• Speaker Impedance: 5.5 OHMS MIN
• Operating Temp: -30° C. TO +60° C
• Storage Temp: -40° C. TO +70° C
• Humidity: 99% (NON CONDENSING)
• Output Voltage: @ 15 VDC @ 11 OHMS 34 V RMS MAX
• Output Power: @ 15 VDC @ 11 OHMS 105 WATTS MAX
• Dimensions: 3.31” (84mm) H x 6” (152mm) W x 7” (178mm) D
• Weight: 4 lbs. 10 oz. (2.1kg)
